Performance features
1. The chassis is powered by the State Ⅲ engine manufactured by Cummins with the power ranging from 180-210 hp optional to the users, characterized by strong power, high reliability, and available to meet the demands of different users; Moreover, it is featured by low engine fuel consumption, energy conservation and environmental protection and superior economical efficiency.
2. The materials of main part for the water tank truck is made of high strength Q345 steel; compared with the ordinary steel materials, its strength is increased by 60% compared with the conventional low-carbon steel under the same thickness; and it can thinner the wall thickness under the same strength and increase the payload mass of the vehicle.
3. The pump mounted on the water sprinkler truck is characterized by heavy displacement, high lift, strong self-priming capability, high output power and high-pressure, etc.
4. The sprinkler system of the water tank truck is mounted with the manual valves and pneumatic valves, thus it is optional for manual and automatic control. The front flushing and rear spraying can be individually and automatically controlled, easy to operate.
5. The arrangement of the sprinkler piping and nozzle is reasonable. A variety of nozzles including column, duck-shaped, shower, etc., are optional for users. By virtue of different nozzle structures and adjustable spray elevation angle, the spray mist and spray column are able to meet different spraying demands.
6. The rear side of the water sprinkler truck is provided with a platform, so that the operator can operate on the platform and conduct long-range spraying operations by virtue of the long-range, high-pressure spray gun.
Technology Parameter
|
Product model
|
YTZ5160GSS20E
|
YTZ5160GSS20F
|
|
Chassis model
|
EQ1168KJ
|
EQ1168GLJ3
|
|
Chassis manufacturer
|
Dongfeng Automobile
|
Dongfeng Automobile
|
|
Dimension(mm)
|
8160×2480×2710
|
8400×2480×2810
|
|
Wheelbase (mm)
|
4500
|
4500
|
|
Front wheel tread(mm)
|
1940
|
1940
|
|
Rear wheel tread(mm)
|
1860
|
1860
|
|
Curb weight (kg)
|
7355
|
7210
|
|
Total mass (kg)
|
16000
|
16000
|
|
Max. speed (km/h)
|
90
|
90
|
|
Max. gradeability (%)
|
30
|
25
|
|
Minimum diameter of turning circle(m)
|
≤18
|
≤18
|
|
Minimum ground clearance(m)
|
≥248
|
≥250
|
|
Approach angle(°)
|
≥25
|
≥24
|
|
Departure Angle(°)
|
≥11
|
≥11
|
|
Effective volume of the tank(m3)
|
8.85
|
9
|
|
Max. watering width(m)
|
≥14
|
≥14
|
|
Longest range of spray gun(m)
|
≥35
|
≥35
|
|
Watering speed(km/h)
|
5-20
|
5-20
|
|
Lifting(m)
|
90
|
90
|
|
Flow(m3/h)
|
60
|
60
|
|
Water intake time(min)
|
<5
|
<5
|
|
Vertical suction distance(m)
|
>6.5
|
>6.5
|
